UL11627 New Energy Battery Cable with 2000V Rated Voltage 105C Working Temperature and Copper Conductor

Name: UL11627 New Energy Battery Cable with 2000V Rated Voltage 105C Working Temperature and Copper Conductor
Brand: MYSUN
Price: 1 USD

Wholesale UL11627 New Energy Battery Cable with 2000V Rated Voltage 105C Working Temperature and Copper Conductor from china suppliers

Model Number : UL11627

Brand Name : MYSUN

Place of Origin : Guangdong, China

MOQ : 500

Conductor Material : Copper

Insulation Material : PVC

Rated Voltage : 2000V

Size Range : 4/0AWG, 3/0AWG, 2/0AWG, 1/0AWG, 2AWG, 4AWG, 6AWG, 8AWG, 3AWG, 5AWG

Working Temperature : 105C

Conductor Diameter : 0.38mm to 3.35mm

Insulation Thickness : 0.78mm

Covering Thickness : 0.13-1.0mm

Max Conductor Resistance : 239Ω/KM to 2.813Ω/KM

Unit Length : 305M to 1220M

Jacket Material : PVC

Conductor Construction : 7/0.127 to 105/0.254

Nominal Diameter : 1.94mm to 4.91mm

Cable Type : High Voltage

UL Standard : UL11627

Contact Now

UL11627 New Energy Cable 2000V 105°C High Voltage PVC Wire

Supplies Fortune 500, Top New Energy Cable Supplier In China

Product Specifications

Size (AWG)	Construction (No./mm)	Diameter (mm)	Nominal Thickness (mm)	Diameter (mm)	Thickness (mm)	Max. Cond Resistance (Ω/KM)	Unit Length (M/Ft)
28	7/0.127	0.38	0.78	1.94	0.13-1.0	239	1220/4000
26	7/0.16	0.50	0.78	2.06	0.13-1.0	150	610/2000
24	7/0.20	0.60	0.78	2.16	0.13-1.0	94.2	610/2000
22	17/0.16	0.76	0.78	2.32	0.13-1.0	59.4	610/2000
20	21/0.18	0.94	0.78	2.50	0.13-1.0	36.7	305/1000
18	16/0.254	1.19	0.78	2.75	0.13-1.0	23.2	610/2000
16	26/0.254	1.50	0.78	3.06	0.13-1.0	14.6	610/2000
14	41/0.254	1.89	0.78	3.45	0.13-1.0	8.96	610/2000
12	65/0.254	2.37	0.78	3.93	0.13-1.0	5.64	610/2000
10	105/0.254	3.02	0.78	4.58	0.13-1.0	3.55	610/2000
9	37/0.475	3.35	0.78	4.91	0.13-1.0	2.813	610/2000

Our Products

UL11627 New Energy Battery Cable with 2000V Rated Voltage 105C Working Temperature and Copper Conductor

Application

Company Profile

Our Overseas Clients

Exhibition

Certifications

Frequently Asked Questions

Who Are We? We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, and our two production bases are located in Dongguan, Guangdong, China and Jingzhou, Hubei, China.
What Can We Provide? We provide high-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, and wiring harnesses.
Why Choose Us? Free samples, competitive pricing, high quality standards, and customized services.
What Certifications Do We Have? UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC certification.
What Services Can We Provide? Accepted delivery terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted payment currency: USD, EUR, CNY. Accepted payment type: T/T, L/C, PayPal, Western Union, Cash.
